Grid column sizes guidelines
For every Grid, explain that the following has to be set:
| Property | Description |
|---|---|
| Column Auto With | Turn Off |
| State Storing | Not dependable on the Workspace |
| Alternating | Turn off Alternating |
| Column Lines | Turn On |
| Datatype | Always set datatype to improve performance (avoid loading 2x) |
| Column Headers | Should all be aligned on the left |
Data types widths & alignment:
| Name | Width | Alignment |
|---|---|---|
| Account Group Name | 150 | left |
| Action Language | 80 | right |
| Article | 120 | right |
| Article Group | 120 | left |
| Assignment Type | 150 | right |
| Billed | 100 | left |
| Billing Client | 100 | left |
| Briefing template | 150 | left |
| Budget | 120 | right |
| Business Object type | 120 | left |
| Business Object Type Level | 100 | left |
| City | 100 | left |
| Client | 160 | left |
| Client Direct | 100 | right |
| Client Group | 100 | left |
| Client Total | 100 | right |
| Code | 120 | left |
| Color | 100 | right |
| Company | 200 | left |
| Contingency Budget | 120 | right |
| Contract | 100 | left |
| Country | 100 | left |
| Currency | 100 | left |
| Date | 100 | center |
| Department | 120 | left |
| Description | 150 | right |
| Division | 120 | left |
| Document | 120 | right |
| Document Type Name | 250 | left |
| 200 | left | |
| Estimate Number | 120 | |
| External ID | 100 | right |
| Finance System Number | 150 | left |
| Head Office | 100 | |
| Hours Type | 100 | right |
| ID | 160 | left |
| Initial Workflow State | 150 | right |
| Integration Error | 120 | right |
| Level | 80 | |
| Manager | 100 | left |
| Margin Type | 100 | right |
| Max Value | 100 | right |
| Member | 180 | right |
| Name | 200 | left |
| Name and External Id | 150 | left |
| Nature | 150 | left |
| Number | 100 | left |
| Number Format | 150 | left |
| Old | 100 | right |
| Order | 80 | right |
| Other Creditor | 100 | left |
| Payment Condition | 120 | left |
| Price | 120 | right |
| Price Table | 100 | left |
| Price Table Column | 120 | left |
| Price With Tax | 120 | right |
| Project | 400 | left |
| Rate Card | 150 | right |
| Rate Card Column | 150 | right |
| Read Role Name | 120 | right |
| Remarks | 100 | left |
| Resource Type | 100 | right |
| Save Role Name | 120 | right |
| Sector | 100 | left |
| Source Code | 400 | right |
| Stage | 200 | left |
| Street | 120 | left |
| Symbol | 80 | right |
| Tags | 150 | right |
| Task Type | 80 | left |
| Title | 300 | left |
| Type | 100 | left |
| Typology | 120 | |
| Typology group | 120 | |
| Unit | 100 | right |
| User | 150 | left |
| Value | 100 | right |
| Vat | 120 | right |
| Vat Deductible Percentage | 100 | right |
| Version | 100 | right |
| Workflow | 100 | left |
| Workflow State Type | 100 | right |
nota
General alignments by datatypes:
- Booleans: center
- Datetime: center
- Number: right
- String: left
